 | Arduino Ep.5 : Piloter Arduino via le Wifi... Upgrade de l'ElekstubeComment utiliser une ESP-01 (esp8266) pour piloter un micro-contrôleur via une communication série... En gros comment piloter un arduino via une page WEB!!! J'upgrade mon Elekstube afin de pouvoir l... La culture maker (de l'anglais make, lit. faiseur) est une culture (ou sous-culture) contemporaine constituant une branche de la culture Do it yourself (DIY) (qu'on peut traduire en français par « faites-le vous-même »). (Source: Wikipedia) |
Arduino
Comment utiliser une ESP-01 (esp8266) pour piloter un micro-contrôleur via une communication série...
En gros comment piloter un arduino via une page WEB!!!
J'upgrade mon Elekstube afin de pouvoir le configurer depuis un téléphone ou une tablette.
🚨Schémas,Sketch, informations sur la page du projet:🚨
http://www.crazymakers.fr/videos-youtube/arduino_ep_5_piloter_arduino_via_le_wifi-art-SaVXwNzeJU4.html
Esp-01:
https://www.ebay.fr/itm/ESP-01-ESP8266-Serial-WIFI-Wireless-Transceiver-Wireless-Module-LWIP-AP-STA/163712418096
Adaptateur Breadboard:
https://www.ebay.fr/itm/2PCS-Breadboard-Adapter-for-ESP8266-ESP-01-ESP-01S-Wifi-Transceiver-Breakout/264539325621
Ftdi Breakout:
https://www.ebay.fr/itm/FTDI-FT232RL-USB-to-Serial-IC-Basic-Breakout-Board-For-Arduino-3-3V-5-5V/202647978588
➕ INFORMATIONS: ➕
⁉️ Catégorie: Arduino.
⏰ Temps: 3 heures.
💪 Difficulté: 6/10.
⭐️ COMMENT NOUS AIDER ? ⭐️
🚨Un petit geste sur Youtip: https://www.utip.io/myprofile
❤️️ Soutenez-nous: http://www.crazymakers.fr/don-crazymakers.html
👍 Pensez à "liker" la vidéo.
🔗 Partagez nos vidéos et parlez de nous autour de vous
📡 NOUS SUIVRE OU NOUS CONTACTER: 📡
🔹Site Internet: http://www.crazymakers.fr
🔹Facebook: https://www.facebook.com/CrazyMakers/
🔹Twitter: https://twitter.com/CrazymakersF
🔹Instagram: https://www.instagram.com/crazymakers_fr/
🔹Chaine Youtube: https://www.youtube.com/c/CrazyMakersFr
Voici comment raccorder l'esp-01 au ftdi breakout
|
||
Voici le sketch à envoyer dans l'esp-01
#include <ESP8266WiFi.h>
#include <WiFiClient.h>
#include <ESP8266WebServer.h>
#include <ESP8266HTTPClient.h>
#include <ESP8266mDNS.h>
const char* ssid = ""; // remplacer par le SSID de votre WiFi
const char* password = ""; // remplacer par le mot de passe de votre WiFi
ESP8266WebServer server(80); // on instancie un serveur ecoutant sur le port 80
//Code HTML du formulaire
void setup(void) {
Serial.begin(115200);
WiFi.hostname("EleksTube");
WiFi.begin(ssid, password);
while (WiFi.status() != WL_CONNECTED) {
delay(500);
}
server.on("/setclock", []() {
String test;
if (server.hasArg("h") && server.hasArg("m") && server.hasArg("s")) {
test += server.arg("h").substring (0,1) + server.arg("col1");
test += server.arg("h").substring (1,2) + server.arg("col2");
test += server.arg("m").substring (0,1) + server.arg("col3");
test += server.arg("m").substring (1,2) + server.arg("col4");
test += server.arg("s").substring (0,1) + server.arg("col5");
test += server.arg("s").substring (1,2) + server.arg("col6");
}
Send_to_Clock("*" + test);
server.send(200, "text/html", "Heure Mise à jour!<br><a href='javascript:history.back();'>Retour</a>");
});
server.on("/", []() {
server.send(200, "text/html", DefautForm);
});
server.on("/setmode", []() {
if (server.hasArg("mode")) {
Send_to_Clock("$0" + server.arg("mode"));}
});
server.begin();
}
void Send_to_Clock(String Command)
{
delay (500);
Serial.println(Command);
server.send(200, "text/html", DefautForm);
}
void loop(void) {
// a chaque iteration, on appelle handleClient pour que les requetes soient traitees
server.handleClient();
}
Le paramétrage d'Arduino avant l'envoi...
|
||
|
||
